S-22ML1E5

FSV VRF Systems (Indoor Unit) (0.8 HP (Wired/Wireless Remote Control))

  • FSV VRF Systems Air Conditioner
  • 2-Way Cassette Type Inverter Heat Pump Indoor Unit



Feature

  • R410A Refrigerant
  • VRF FSV Systems Air Conditioner
  • 2-way Cassette Type
  • Cooling 7,500 BTU/h (2.2kW)
  • Heat Pump 8,500 BTU/h (2.5kW)
  • Size (HxWxD)
    Indoor Unit: 350x840x600mm
    Panel: 8x1060x680mm
  • Supported with Panasonic Comfort Cloud App (Installation of WiFi Adapter CZ-CAPWFC1 is required)
  • http://shew.com.hk/english/brand/panasonic/ventilation-and-air-conditioning/air-conditioner/fsv-vrf-systems/air-conditioner-accessories/cz-capwfc1.aspx

Specifications

S-22ML1E5
S-22ML1E5
Cooling Capacity 7,500 BTU/h (2.2kW)
Heating Capacity 8,500 BTU/h (2.5kW)
Electrical Data 220 Voltage (V)
Power input Cooling 0.095 kW
Heat Pump 0.062 kW
Net Weight Indoor Unit 23kg
Panel 5.5kg
Size (H x W x D) Indoor Unit 350x840x600mm
Panel 8x1060x680mm
Combination of Outdoor Unit U-8ME2H7
U-10ME2H7
U-12ME2H7
U-14ME2H7
U-16ME2H7
U-18ME2H7
U-20ME2H7
U-8LE1H7
U-10LE1H7
U-8MF3R7
U-10MF3R7
U-12MF3R7
U-14MF3R7
U-16MF3R7
U-4LE2H4
U-5LE2H4
U-6LE2H4
U-4LE2H7
U-5LE2H7
U-6LE2H7
* The product is subject to the actual product. Photos and product shots are for reference only. The actual color and size may vary slightly from those shown.
* Product specifications are subject to change without prior notice.
